Features
- 2.0 Megapixel high-performance CMOS
- Plastic Body
- Analog HD output
- Up to 1920P resolution
- Digital Wide Dynamic Range
- STD/HIGH-SAT Image Mode
- True Day/Night - ICR
- Max. 2.7 W Power Consumption
- Brightness, Sharpness, Mirror, Smart IR
- Up to 30m IR distance
- 2D DNR Noise Reduction
- Audio over coaxial cable
- IP67 weatherproof
- Built-in mic
- 4 signals Switchable TVI/AHD/CVI/CVBS.
Specifications
General
DimensionsΦ 84.6 mm × 78.9 mm (Φ 3.33″ × 3.11″)WeightApprox. 140.5 g (0.31 lb.)Pan/Tilt/RotationPan: 0 to 360°,
Tilt: 0 to 75°,
Rotation: 0 to 360°Operating Conditions-40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing)Power Supply12 VDC ± 25%Power ConsumptionMax. 2.7 W
Camera
Image Sensor2 MP CMOSElectronic Shutter SpeedPAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 sMinimum Illumination0.01 Lux @ (F1.2, AGC ON), 0 Lux with IRIR Distance20 m
Lens
Focal Length2.8 mm, 3.6 mm, 6 mm fixed focal lens
Video
Resolution1920 × 1080 resolutionFrame RateTVI: 1080P@30fps, 1080P@25fps AHD: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps CVBS: PAL/NTSCVideo OutputVideo OutputSwitchable TVI/AHD/CVI/CVBSDay/NightICRBLC ModeYesNoise Reduction2D DNR
Interface
Audio InterfaceAudio over coaxial cable, built-in mic
Warranty
Warranty6 months of warranty
